Engineered for long term offshore deployment on WTG foundation platforms. Marine grade corrosion resistance via stainless steel chassis and C5(H) marine grade paint coating.
Carefully designed and engineered for deployment in harsh, remote conditions. All components are demountable and easily exchanged. Easy clean surfaces. Minimal inspection burden.
| External Dimensions | 2251mm (H) × 1202mm (W) × 1202mm (D) |
|---|---|
| Dry Weight | 350kg |
| Chassis | Stainless steel with C5(H) marine grade paint coating |
| Walls & Roof | Insulated composite panels — galvanised steel inner and outer skins with polyurethane core |
| Floor | Corrosion-resistant |
| Door | Watertight steel door with perspex window |
| Lifting | Single-point top-mounted lifting eye |
| Power | External IP-rated input. Accepts generator, fixed grid (WTG / FOU) or battery sources |
| Lighting | Internal LED with PIR control. Natural daylight via perspex window in door |
| Ventilation | Passive — high and low diagonal vents on opposing sides. External cowls reduce water ingress |
